앰프/리시버 온쿄 인티앰프 A-8017







온쿄 인티앰프 A-8017입니다.

220V

435 x 142 x 392 mm (WxHxD).

85W+85W. 0.015

포노단, MM, MC 선택사용할 수 있습니다.

스피커, A, B, A+B

온쿄에서 신경써서 만든 고급 앰프입니다.

전 기능 이상없으며 잡음없이

깨끗한 음질들으실 수 있습니다.

실물사진입니다.

착불 만원

010-3151-3159



Technical Data

Continuous power (at distortion factor)

8 Ohm: 2x 85 W

4 Ohm: 2x 115 W



Dynamic power

8 Ohm: 2x 110 W

4 Ohm: 2x 165 W

Total harmonic distortion: 0.015%

Intermodulation distortion: 0,005%

Attenuation factor: 50 (1 kHz, 8 Ohm)

Frequency response: 2 - 50,000Hz

Signal-to-noise ratio phono (MM): 80dB

Signal-to-noise ratio phono (MC): 68dB



Signal-to-noise ratio tuner, tape: 84dB

Stereo channel separation:

Tone control:

Bass: ±8 db at 70 Hz

Treble: ±8 db at 20 kHz



Loudness: +6db at 70Hz/+5dB at 20kHz

High Filter:

Low Filter (Subsonic):

Mute:

Direct/Line-Straight:



General

Manufacturer: Onkyo

Model: A-8017 - [Integra Series]

Type: Integrated amplifier

Years of manufacture: 1983 - 1985

Made in: Japan

Colour: Silver and black

Remote control: none

Power consumption:

Dimensions: 435 x 142 x 392 mm (WxHxD).

Weight: 11.5 kg

Original price approx.: 998 DM



Connections

Number of inputs: 6

Phono (MM): 2.5 mV / 50 kOhm / 220pF

Phono (MC): 280 µV / 330 Ohm

Tape 1/2: 150 mV / 50 kOhm

CD/AUX

Tuner: 150 mV / 50 kOhm

Number of outputs: 3

2 pairs of speakers (A/B)

Headphones
